DMOM-100/200 Series 2 Operating Procedures
31
Rev 2, 2009
7.9 Reviewing a Record
This procedure describes the steps for reviewing a test record residing in the DMOM’s working
memory. The user can view the record on the LCD display or print the record on the thermal
printer.
The view feature is useful when the user wants to review a test record stored in the DMOM’s
Flash EEPROM and there is no thermal paper for printing.
NOTE
To review a test record stored in Flash EEPROM, the user must first restore the test record from
Flash EEPROM to working memory (see paragraph 7.10, Restore Record Procedure).
Table 8.0 Review Record Procedure
STEP ACTION DMOM DISPLAY
8-1 On the START MENU, press key # 2
(SETUP) to select the SETUP MENU
(shown at right).
8-2 Press key# 2 (REVIEW RECORD) on the
SETUP MENU. The REVIEW RECORD
menu will be displayed.
8-3 If a record’s test results are to be reviewed
from a printout, press key # 2 to select the
PRINT TEST RECORD option. The
PLEASE WAIT PRINTING… screen will
be displayed while printing is in progress.
When printing is complete, the display will
return to the START MENU. This ends the
procedure for the PRINT TEST RECORD
option.
8-4 If records are to be viewed in sequence by
scrolling the records on the LCD, press key #
1 to select the SCROLL TEST RECORDS
option in the REVIEW RECORD menu. The
RECORD ID INFO screen will appear. press
one of the scroll keys (
∧ and ∨) to begin
scrolling through the test records. The
“number of tests” display will appear.
1. ENTER ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
REVIEW RECORD
1. SCROLL TEST RECORD
2. PRINT TEST RECORD
PLEASE WAIT
PRINTING . . .
RECORD ID INFO:
