DMOM-100/200 Series 2 Operating Procedures
23
Rev 2, 2009
Table 5.0 Run Test Procedure (Measure an Unknown Resistance Continued)
STEP ACTION DMOM DISPLAY
5-5 The SELECT RAMP TIME menu will
appear. Push a key (1 through 4) to select a
Ramp Time. For this example, push key # 1
to select 5 SEC (5 seconds).
5-6 The display will show the selected test
current, burn-in time, and ramp time.
NOTE
5-second burn-in and ramp times were
selected in this example.
5-7 Press the START key to run the resistance
measurement test. A display of the ramping
current and the percentage of ramp level
will be displayed, along with the notices
TEST IN PROGRESS and PLEASE
WAIT.
5-8 Automatic. No operator action is required.
Current, burn-in time, and resistance
measurement changes will appear on the
display during the burn-in.
5-9 Automatic. No operator action is required.
At the end of the burn-in time, the current is
ramped back down to zero. The ramp
percentage will be displayed.
5-10 Automatic. No operator action is required.
At the end of the burn-in time, the final
resistance measurement will be displayed.
Press the ENTER key to go to next display.
5-11 The PRINT RESULTS option menu will
be displayed.
5-12 Press key # 1 to print. The PRINTING
menu will be displayed during printing. A
typical printout is shown in Figure 15.0.
If no printout is needed, press key # 2. Go to
the next step.
5-13 After the test report completes printing, or if
key # 2 was pressed, the KEEP THIS
READING menu will be displayed.
CURRENT: 100 AMPS
RAMPING CURRENT 10%
TEST IN PROGRESS
PLEASE WAIT
CURRENT: 100 AMPS
BURNING-IN: 05
100.5 MICRO-OHMS
PLEASE WAIT
FINAL RESISTANCE
I= 100 AMPS
100.5 MICRO-OHMS
PRINT TEST RESULTS?
1. YES
2. NO
PRINTING REPORT
PLEASE WAIT…
KEEP THIS READING?
1. YES
2. NO
CURRENT: 100 AMPS
BURN-IN: 5 SEC
RAMP: 5 SEC
“START” TO RUN TEST
SELECT RAMP TIME:
1. 5 SEC
2. 10 SEC
3. 20 SEC 4. 30 SEC
FINAL RESISTANCE
RAMPING CURRENT: xx%
100.5 MICRO-OHMS
