9 . specifications – Staub Electronics B-500-RX-230-IR BINARY - HD BASE T RECEIVER WITH BI-DIRECTIONAL IR FOR B-500 HDBASET MATRIX SWITCHERS User Manual
Page 11
pg.11
www.snapav.com Support: 866.838.5052
B-500-RX-230-IR Installation Manual
9 . Specifications
TECHNICAL
HDMI Compliance
HDMI 3D
HDCP Compliance
Yes
Video Bandwidth
10.2 Gbps
HDMI over UTP Transmission
Resolution
Cat5e/ Cat6
Cat6a
1080i / 720p 24-bit color
200ft
230ft
Full HD 1080P 24-bit color
200ft
230ft
Full HD 1080P 36-bit deep color
200ft
230ft
Input TMDS Signal
1.2 Volts (peak-to-peak)
Input DDC Signal
5 Volts (peak-to-peak, TTL)
ESD Protection
(1) Human body model — ±15kV (air-gap discharge) & ±8kV
(contact discharge) (2) Core chipset — ±8kV
IR Signal (Bi-directional)
Carrier frequency: 20-60kHz
CONNECTIONS
HDBaseT Link
1x RJ45
HDMI
1x HDMI Type A (19-pin female)
IR Receiver
1x 3.5mm Stereo (Powered)
IR Flasher
1x 3.5mm Mono
Power
Latch-Locking
USB Update Port
Mini USB - Factory Use Only
MECHANICAL
Housing
Metal enclosure
Dimensions (Inches, W x H x D)
4.1” x 1.25” x 3.5”
Weight
1.1 lbs.
Power Supply
5V DC 2A
Power Consumption
7.5w (max)
Operation Temperature
32~104°F
Storage Temperature
-4~140°F
Relative Humidity
20~90% RH (no condensation)
Certifications and Compliance
Product: CE, FCC, Rohs
Power Supply: CE, FCC, Rohs, UL
