SM-RAZOR-F Installation and Users Manual

WARNINGS:

• Installation of this product should be done by a qualified professional.
• Do not begin installation before reviewing and understanding these instructions.
• Ensure the mounting wall used can safely support 4 times the combined weight of

the mount and chosen display.

• Under no circumstances should this product be mounted to metal studs.
• The manufacturer does not accept responsibility for incorrect installation.

SPECIFICATIONS

Maximum Load:
SM-RAZOR-F-M 100 lbs.
SM-RAZOR-F-L 100 lbs.
SM-RAZOR-F-XL 150 lbs.

VESA Patterns:
SM-RAZOR-F-M: Up to VESA 400x300
SM-RAZOR-F-L: Up to VESA 600x400
SM-RAZOR-F-XL: Up to VESA 800x600

TOOLS REQUIRED

• Power Drill
• 5/6” and 3/16” Drill Bit
• Phillips Head Screw Driver
• Level
• 3/8” Socket Wrench
• Hammer
• Stud Finder

CAUTION:

This wall mount is intended for use only with the maximum weight

of 100 lbs for models SM-RAZOR-F-M & SM-RAZOR-F-L; 150 lbs for model SM-

RAZOR-F-XL. Use with heavier than the maximum weight indicated may result in

instability causing possible injury.
