ADSP-TS201S

U1

MSSD0

V1

MSSD2

W1

CONTROLIMP0

Y1

EMU

U2

RST_OUT

V2

DS2

W2

ENEDREG

Y2

TCK

U3

ID2

V3

POR_IN

W3

TDI

Y3

TMR0E

U4

DS1

V4

CONTROLIMP1

W4

TDO

Y4

FLAG3

U5

V

DD_IO

V5

V

SS

W5

V

DD_IO

Y5

V

SS

U6

V

DD

V6

V

DD

W6

V

DD

Y6

V

DD_IO

U7

V

DD

V7

V

DD

W7

V

DD

Y7

V

SS

U8

V

SS

V8

V

DD

W8

V

DD

Y8

V

DD_IO

U9

V

SS

V9

V

DD

W9

V

DD

Y9

V

SS

U10

V

DD

V10

V

DD

W10

V

DD

Y10

V

DD_IO

U11

V

DD_DRAM

V11

V

DD_DRAM

W11

V

DD_DRAM

Y11

V

DD_IO

U12

V

SS

V12

V

DD_DRAM

W12

V

DD_DRAM

Y12

V

DD_IO

U13

V

SS

V13

V

DD

W13

V

DD

Y13

V

DD_IO

U14

V

SS

V14

V

DD

W14

V

DD

Y14

V

DD_IO

U15

V

SS

V15

V

DD_DRAM

W15

V

DD_DRAM

Y15

V

DD_IO

U16

V

SS

V16

V

DD_DRAM

W16

V

DD_DRAM

Y16

V

SS

U17

V

SS

V17

V

DD

W17

V

DD

Y17

V

DD_IO

U18

V

DD

V18

V

DD

W18

V

DD

Y18

V

SS

U19

V

DD

V19

V

DD

W19

V

DD

Y19

V

DD_IO

U20

V

DD_IO

V20

V

DD_IO

W20

V

DD_IO

Y20

V

SS

U21

L1CLKINN

V21

L1DATI3_N

W21

L1CLKON

Y21

L1DATO1_N

U22

L1CLKINP

V22

L1DATI3_P

W22

L1CLKOP

Y22

L1DATO1_P

U23

L1DATI1_N

V23

L1DATI2_N

W23

L1DATO3_N

Y23

L1DATO2_N

U24

L1DATI1_P

V24

L1DATI2_P

W24

L1DATO3_P

Y24

L1DATO2_P

AA1

FLAG2

AB1

V

SS

AC1

FLAG0

AD1

V

SS

AA2

FLAG1

AB2

V

SS

AC2

V

SS

AD2

ID1

AA3

IRQ3

AB3

V

SS

AC3

V

DD_IO

AD3

V

DD_IO

AA4

V

SS

AB4

NC

AC4

TMS

AD4

TRST

AA5

IRQ0

AB5

IRQ2

AC5

IOWR

AD5

IORD

AA6

IOEN

AB6

IRQ1

AC6

DMAR2

AD6

DMAR3

AA7

DMAR0

AB7

DMAR1

AC7

CPA

AD7

DPA

AA8

HBR

AB8

HBG

AC8

BOFF

AD8

BUSLOCK

AA9

L3BCMPO

AB9

L3ACKI

AC9

L3DATO0_N

AD9

L3DATO0_P

AA10

L3DATO1_N

AB10

L3DATO1_P

AC10

L3CLKON

AD10

L3CLKOP

AA11

L3DATO3_N

AB11

L3DATO3_P

AC11

L3DATO2_N

AD11

L3DATO2_P

AA12

V

SS

AB12

V

SS

AC12

L3DATI3_N

AD12

L3DATI3_P

AA13

L3DATI2_N

AB13

L3DATI2_P

AC13

L3CLKINN

AD13

L3CLKINP

AA14

L3DATI1_N

AB14

L3DATI1_P

AC14

L3DATI0_N

AD14

L3DATI0_P

AA15

NC

AB15

V

SS

AC15

L3ACKO

AD15

L3BCMPI

AA16

L2DATO0_N

AB16

L2DATO0_P

AC16

L2BCMPO

AD16

L2ACKI

AA17

L2CLKON

AB17

L2CLKOP

AC17

L2DATO1_N

AD17

L2DATO1_P

AA18

L2DATO3_N

AB18

L2DATO3_P

AC18

L2DATO2_N

AD18

L2DATO2_P

AA19

L2CLKINN

AB19

L2CLKINP

AC19

L2DATI3_N

AD19

L2DATI3_P

AA20

L2DATI1_N

AB20

L2DATI1_P

AC20

L2DATI2_N

AD20

L2DATI2_P

AA21

V

SS

AB21

L2ACKO

AC21

L2DATI0_N

AD21

L2DATI0_P

AA22

L1BCMPO

AB22

V

SS

AC22

V

DD_IO

AD22

V

DD_IO

AA23

L1DATO0_N

AB23

V

DD_IO

AC23

V

SS

AD23

L2BCMPI

AA24

L1DATO0_P

AB24

V

DD_IO

AC24

L1ACKI

AD24

V

SS

1

On revision 1.x silicon, the R2 and R3 balls are NC. On revision 0.x silicon, the R2 ball is SCLK, and the R3 ball is SCLK_V

REF

. For more information on SCLK and SCLK_V

REF

on revision 0.x silicon, see the EE-179: ADSP-TS20x TigerSHARC System Design Guidelines on the Analog Devices website (www.analog.com).

Table 35. 576-Ball (25 mm × 25 mm) BGA_ED Ball Assignments (Continued)

Ball No. Signal Name

Ball No. Signal Name

Ball No. Signal Name

Ball No. Signal Name
