GENERAL DESCRIPTION
The ADSP-TS201S TigerSHARC processor is an ultrahigh per-
formance, static superscalar processor optimized for large signal
processing tasks and communications infrastructure. The DSP
combines very wide memory widths with dual computation
blocks—supporting floating-point (IEEE 32-bit and extended
precision 40-bit) and fixed-point (8-, 16-, 32-, and 64-bit) pro-
cessing—to set a new standard of performance for digital signal
processors. The TigerSHARC static superscalar architecture lets
the DSP execute up to four instructions each cycle, performing
24 fixed-point (16-bit) operations or six floating-point
operations.
Four independent 128-bit wide internal data buses, each con-
necting to the six 4M bit memory banks, enable quad-word
data, instruction, and I/O access and provide 33.6G bytes per
second of internal memory bandwidth. Operating at 600 MHz,
the ADSP-TS201S processor’s core has a 1.67 ns instruction
cycle time. Using its single-instruction, multiple-data (SIMD)
features, the ADSP-TS201S processor can perform 4.8 billion,
40-bit MACS or 1.2 billion, 80-bit MACS per second.
Table 1
shows the DSP’s performance benchmarks.
The ADSP-TS201S processor is code compatible with the other
TigerSHARC processors.
The Functional Block Diagram on Page 1 shows the
ADSP-TS201S processor’s architectural blocks. These blocks
include:
• Dual compute blocks, each consisting of an ALU, multi-
plier, 64-bit shifter, 128-bit CLU, and 32-word register file
and associated data alignment buffers (DABs)
• Dual integer ALUs (IALUs), each with its own 31-word
register file for data addressing and a status register
• A program sequencer with instruction alignment buffer
(IAB) and branch target buffer (BTB)
• An interrupt controller that supports hardware and soft-
ware interrupts, supports level- or edge-triggers, and
supports prioritized, nested interrupts
• Four 128-bit internal data buses, each connecting to the six
4M bit memory banks
• On-chip DRAM (24M bit)
• An external port that provides the interface to host proces-
sors, multiprocessing space (DSPs), off-chip memory-
mapped peripherals, and external SRAM and SDRAM
• A 14-channel DMA controller
• Four full-duplex LVDS link ports
• Two 64-bit interval timers and timer expired pin
• An 1149.1 IEEE-compliant JTAG test access port for on-
chip emulation
Figure 2 on Page 3 shows a typical single-processor system with
external SRAM and SDRAM. Figure 4 on Page 8 shows a typical
multiprocessor system.
Table 1. General-Purpose Algorithm Benchmarks
at 600 MHz
Benchmark Speed
Clock
Cycles
32-bit algorithm, 1.2 billion MACS/s peak performance
1K point complex FFT 1 (Radix2) 15.7 μs 9419
64K point complex FFT 1 (Radix 2) 2.33 ms 1397544
FIR filter (per real tap) 0.83 ns 0.5
[8 Ч 8][8 Ч 8] matrix multiply (complex,
floating-point)
2.3 μs 1399
16-bit algorithm, 4.8 billion MACS/s peak performance
256 point complex FFT 1 (Radix 2)
1 Cache preloaded
0.975 μs 585
I/O DMA transfer rate
External port 1G bytes/s n/a
Link ports (each) 1G bytes/s n/a
