Rev. C

|

Page 22 of 48

|

December 2006

ADSP-TS201S

ELECTRICAL CHARACTERISTICS

Table 18. Maximum Duty Cycle for Input Transient Voltage

V

IN

Max (V)

1

V

IN

Min (V)

1

Maximum Duty
Cycle

2

+3.63

–0.33

100%

+3.64

–0.34

90%

+3.70

–0.40

50%

+3.78

–0.48

30%

+3.86

–0.56

17%

+3.93

–0.63

10%

1

The individual values cannot be combined for analysis of a single instance of

overshoot or undershoot. The worst case observed value must fall within one of
the voltages specified and the total duration of the overshoot or undershoot
(exceeding the 100% case) must be less than or equal to the corresponding duty
cycle.

2

Duty cycle refers to the percentage of time the signal exceeds the value for the

100% case. This is equivalent to the measured duration of a single instance of
overshoot or undershoot as a percentage of the period of occurrence. The
practical worst case for period of occurrence for either overshoot or undershoot
is 2 × t

SCLK

.

Parameter Description

Test Conditions

Min

Max

Unit

V

OH

High Level Output Voltage

1

1

Applies to output and bidirectional pins.

@V

DD_IO

= Min, I

OH

= –2 mA

2.18

V

V

OL

Low Level Output Voltage

1

@V

DD_IO

= Min, I

OL

= 4 mA

0.4

V

I

IH

High Level Input Current

@V

DD_IO

= Max, V

IN

= V

IH

Max

20

μA

I

IH_PU

High Level Input Current

@V

DD_IO

= Max, V

IN

= V

IH

Max

20

μA

I

IH_PD

High Level Input Current

@V

DD_IO

= Max, V

IN

= V

DD_IO

Max

0.3

0.76

mA

I

IH_PD_L

High Level Input Current

@V

DD_IO

= Max, V

IN

= V

IH

Max

30

76

μA

I

IL

Low Level Input Current

@V

DD_IO

= Max, V

IN

= 0 V

20

μA

I

IL_PU

Low Level Input Current

@V

DD_IO

= Max, V

IN

= 0 V

0.3

0.76

mA

I

IL_PU_AD

Low Level Input Current

@V

DD_IO

= Max, V

IN

= 0 V

30

100

μA

I

OZH

Three-State Leakage Current High

@V

DD_IO

= Max, V

IN

= V

IH

Max

50

μA

I

OZH_PD

Three-State Leakage Current High

@V

DD_IO

= Max, V

IN

= V

DD_IO

Max

0.3

0.76

mA

I

OZL

Three-State Leakage Current Low

@V

DD_IO

= Max, V

IN

= 0 V

20

μA

I

OZL_PU

Three-State Leakage Current Low

@V

DD_IO

= Max, V

IN

= 0 V

0.3

0.76

mA

I

OZL_PU_AD

Three-State Leakage Current Low

@V

DD_IO

= Max, V

IN

= 0 V

30

100

μA

I

OZL_OD

Three-State Leakage Current Low

@V

DD_IO

= Max, V

IN

= 0 V

4

7.6

mA

C

IN

Input Capacitance

2, 3

2

Applies to all signals.

3

Guaranteed but not tested.

@f

IN

= 1 MHz, T

CASE

= 25

°C, V

IN

= 2.5 V

3

pF

Parameter name suffix conventions: no suffix = applies to pins without pull-up or pull-down resistors, _PD = applies to pin types (pd) or
(pd_0), _PU = applies to pin types (pu) or (pu_0), _PU_AD = applies to pin types (pu_ad), _OD = applies to pin types OD, _PD_L = applies
to pin types (pd_l)
