Table 9. Pin Definitions—JTAG Port
Signal
Type
Term
Description
EMU
O/OD
nc
1
Emulation. Connected to the DSP’s JTAG emulator target board connector only.
TCK
I
epd or epu
Test Clock (JTAG). Provides an asynchronous clock for JTAG scan.
TDI
I (pu_ad)
nc
Test Data Input (JTAG). A serial data input of the scan path.
TDO
O/T
Test Data Output (JTAG). A serial data output of the scan path.
TMS
I (pu_ad)
nc
Test Mode Select (JTAG). Used to control the test state machine.
TRST
I/A (pu_ad)
na
Test Reset (JTAG). Resets the test state machine. TRST must be asserted or pulsed low
after power up for proper device operation. For more information, see
.
I = input; A = asynchronous; O = output; OD = open-drain output; T = three-state; P = power supply; G = ground; pd = internal pull-down
5 k
Ω
; pu = internal pull-up 5 k
Ω
; pd_0 = internal pull-down 5 k
Ω
on DSP ID = 0; pu_0 = internal pull-up 5 k
Ω
on DSP ID = 0; pu_od_0 = internal
pull-up 500
Ω
on DSP ID = 0; pd_m = internal pull-down 5 k
Ω
on DSP bus master; pu_m = internal pull-up 5 k
Ω
on DSP bus master; pu_ad
= internal pull-up 40 k
Ω
. For more pull-down and pull-up information, see
Electrical Characteristics on Page 22
Term (termination of unused pins) column symbols: epd = external pull-down approximately 5 k
Ω
to V
SS
; epu = external pull-up approx-
imately 5 k
Ω
to V
DD_IO
, nc = not connected; na = not applicable (always used); V
DD_IO
= connect directly to V
DD_IO
; V
SS
= connect directly to V
SS
1
See the reference
to the JTAG emulation technical reference EE-68.
Table 10. Pin Definitions—Flags, Interrupts, and Timer
Signal
Type
Term
Description
FLAG3–0
I/O/A
(pu)
nc
FLAG pins. Bidirectional input/output pins can be used as program conditions. Each pin
can be configured individually for input or for output. FLAG3–0 are inputs after power-up
and reset.
IRQ3–0
I/A
(pu)
nc
Interrupt Request. When asserted, the DSP generates an interrupt. Each of the IRQ3–0 pins
can be independently set for edge-triggered or level-sensitive operation. After reset, these
pins are disabled unless the IRQ3–0 strap option and interrupt vectors are initialized for
booting.
TMR0E
O
na
Timer 0 expires. This output pulses whenever timer 0 expires. At reset, this is a strap pin.
For more information, see
I = input; A = asynchronous; O = output; OD = open-drain output; T = three-state; P = power supply; G = ground; pd = internal pull-down
5 k
Ω
; pu = internal pull-up 5 k
Ω
; pd_0 = internal pull-down 5 k
Ω
on DSP ID = 0; pu_0 = internal pull-up 5 k
Ω
on DSP ID = 0; pu_od_0 = internal
pull-up 500
Ω
on DSP ID = 0; pd_m = internal pull-down 5 k
Ω
on DSP bus master; pu_m = internal pull-up 5 k
Ω
on DSP bus master; pu_ad
= internal pull-up 40 k
Ω
. For more pull-down and pull-up information, see
Electrical Characteristics on Page 22
Term (termination of unused pins) column symbols: epd = external pull-down approximately 5 k
Ω
to V
SS
; epu = external pull-up approx-
imately 5 k
Ω
to V
DD_IO
, nc = not connected; na = not applicable (always used); V
DD_IO
= connect directly to V
DD_IO
; V
SS
= connect directly to V
SS
