Table 29. AC Signal Specifications
(All values in this table are in nanoseconds.)
Name Description In
put S
e
tu
p
(M
in
)
In
put Hold
(M
in
)
Ou
tp
u
t V
a
li
d
(M
a
x
)
Ou
tp
u
t H
o
ld
(M
in
)
Ou
tp
u
t En
ab
le
(M
in
) 1
Ou
tpu
t Di
sab
le
(M
a
x
) 1
Re
fe
re
nce
Cl
ock
ADDR31–0 External Address Bus 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
DATA63–0 External Data Bus 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
MSH Memory Select HOST Line — — 4.0 1.0 1.15 2.0 SCLK
MSSD3–0 Memory Select SDRAM Lines 1.5 0.5 4.0 1.0 1.0 2.0 SCLK
MS1–0 Memory Select for Static Blocks — — 4.0 1.0 1.15 2.0 SCLK
RD Memory Read 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
WRL Write Low Word 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
WRH Write High Word 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
ACK Acknowledge for Data High to Low 1.5 0.5 3.6 1.0 1.15 2.0 SCLK
Acknowledge for Data Low to High 1.5 0.5 4.2 0.9 1.15 2.0 SCLK
SDCKE SDRAM Clock Enable 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
RAS Row Address Select 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
CAS Column Address Select 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
SDWE SDRAM Write Enable 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
LDQM Low Word SDRAM Data Mask — — 4.0 1.0 1.15 2.0 SCLK
HDQM High Word SDRAM Data Mask — — 4.0 1.0 1.15 2.0 SCLK
SDA10 SDRAM ADDR10 — — 4.0 1.0 1.15 2.0 SCLK
HBR Host Bus Request 1.5 0.5 — — — — SCLK
HBG Host Bus Grant 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
BOFF Back Off Request 1.5 0.5 — — — — SCLK
BUSLOCK Bus Lock — — 4.0 1.0 1.15 2.0 SCLK
BRST Burst Pin 1.5 0.5 4.0 1.0 1.15 2.0 SCLK
BR7–0 Multiprocessing Bus Request Pins 1.5 0.5 4.0 1.0 — — SCLK
BM Bus Master Debug Aid Only — — 4.0 1.0 — — SCLK
IORD I/O Read Pin — — 4.0 1.0 1.0 2.0 SCLK
IOWR I/O Write Pin — — 4.0 1.0 1.15 2.0 SCLK
IOEN I/O Enable Pin — — 4.0 1.0 1.15 2.0 SCLK
CPA Core Priority Access High to Low 1.5 0.5 4.0 1.0 0.75 2.0 SCLK
Core Priority Access Low to High 1.5 0.5 29.5 2.0 0.75 2.0 SCLK
DPA DMA Priority Access High to Low 1.5 0.5 4.0 1.0 0.75 2.0 SCLK
DMA Priority Access Low to High 1.5 0.5 29.5 2.0 0.75 2.0 SCLK
BMS Boot Memory Select — — 4.0 1.0 1.15 2.0 SCLK
FLAG3–0 2 FLAG Pins — — 4.0 1.0 1.15 2.0 SCLK
RST_IN 3, 4 Global Reset Pin 1.5 2.5 — — — — SCLK 5
TMS Test Mode Select (JTAG) 1.5 0.5 — — — — TCK
TDI Test Data Input (JTAG) 1.5 0.5 — — — — TCK
TDO Test Data Output (JTAG) — — 4.0 1.0 0.75 2.0 TCK 6
TRST 3, 4 Test Reset (JTAG) 1.5 0.5 — — — — TCK
EMU 7 Emulation High to Low — — 5.5 2.0 1.15 4.0 TCK or SCLK
ID2–0 8 Static Pins—Must Be Constant — — — — — — —
CONTROLIMP1–0 8 Static Pins—Must Be Constant — — — — — — —
