User Manual Page 70
3. GVRP registration: C GVRP registration drop-down menu from GVRP registration
drop-down list to choose Enable or Disable to enable or disable GVRP registration to
the port. Configuring an IEEE802.1Q trunk port in registration mode allows dynamic
creation (if dynamic VLAN creation is enabled), registration, and deregistration of
VLANs on the trunk port.
4. Update Setting: C Update Setting button when you finished Per port setting.
IGMP Snooping
1. - -down list to
for the switch. Disable: Disable IGMP on the
switch. Passive: The switch with only multicast-data-forwarding capability. Querier: The
switch acts as the querier for the network. There is only one querier on a network at
any time.
2. Update Setting: C Update Setting button when you finished IGMP mode settings.
3. VLAN ID: VLAN ID - VLAN ID -down list to choose
the VLAN under configuration for the switch.
4. IGMP version: version -down me version -down
1 2 3 for the switch.
5. Fast-leave: fast-leave - fast-leave -down list to
Enable Disable for the switch. Enable this function will allow members of a
multicast group to leave the group immediately when an IGMP Leave Report Packet is
received by the Switch.
IGMP querier:
1. Query-interval:
query-interval textbox and specify a new number from 1 ~
18000. The query-interval field is used to set the time (in seconds) between
transmitting IGMP queries. Entries between 1 and 18000 seconds are allowed. Default
= 125.
2. Max-response-time: max-response-time textbox and specify a new
number from 1 ~ 124. This determines the maximum amount of time in seconds
allowed before sending an IGMP response report. The max-response-time field allows
