User Manual Page 129
Strict Priority:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use priority-queue out command to enable the egress expedite queue.
Use the no priority-queue out command to disable the egress expedite queue.
3. Command Syntax:
(no) priority-queue out
4. Example:
The following example enables the egress expedite queue on the switch:
switch_a(config)#priority-queue out
switch_a(config)#
Weighted Round Robin:
1. Command Mode: Configure mode
Logon to Configure Mode (Configure Terminal Mode).
The switch_a(config)# prompt will show on the screen.
switch_a(config)#
2. Usage:
Use wrr-queue bandwidth command to specify the bandwidth ratios of the transmit
queues.
3. Command Syntax:
wrr-queue bandwidth WRR_WTS
WRR_WTS Weighted Round Robin (WRR) weights for the 4 queues (4 values separated by
spaces). Range is 1-55.
4. Example:
The following example specifies the bandwidth ratios of the transmit queues on the
switch:
switch_a(config)#wrr-queue bandwidth 1 2 4 8
switch_a(config)#
802.1p Priority
1. Command Mode: Configure mode
