4.
Appendix
32
� I/O Parameter
No. Parameter name
Default
(reference)
Input
Range
Unit Remarks
225 Network I/F Module Control 6H
Only
referring
(HEX)
-
Bit 0 to 3: Type of Network I/F Module
Control 1
(0: Not Mounted
1: CC-Link,
2: DeviceNet,
3: Profibus,
4 to 5: System Reservation,
6: EtherCAT,
7: EtherNet/IP)
Bit 4 to 7: Type of Network I/F Module
Control 2
(0: Not Mounted
1: CC-Link,
2: DeviceNet,
3: Profibus,
4 to 7: System Reservation)
226 Network I/F Module 1
Node Address
17 0 to 65535 -
• At CC-Link : 1 to 64
• At DeviceNet : 0 to 63
• At Profibus : 0 to 125
* Setting establishment not necessary for
EtherCAT (Make setting from master) �
227 Network I/F Module 1
Baud Rate
0 0 to 9 -
• At CC-Link:
(0: 156kbps, 1: 625kbps, 2: 2.5Mbps,
3: 5Mbps, 4: 10Mbps)
• At DeviceNet�
(0: 125kbps, 1: 250kbps, 2: 500kbps)
• At EtherNet/IP:
(0: Autonegotiation,
1: 10Mbps (Half-Duplex),
2: 10Mbps (Full duplex),
3: 100Mbps (Half-Duplex),
4: 100Mbps (Full duplex))
* Setting establishment not necessary for
Profibus and EtherCAT
*The the actual default value may differ depending on the construction of used option board.
