4.
Appendix
30
� Cold Start Level Errors
No. Error name Contents / Counteractions
678
Extension I/O Port Assignment
Parameter Error
There is an error in a parameter related to the extended I/O port
assignment.
679
Extended I/O Port Assignment Number
Overflow Error
The number of extended I/O port assignment exceeded the
specification range.
67A
Extended I/O Port Duplicated
Assignment Error
Extended I/O port assignment has duplicated.
D56
Fieldbus Error
(MinACK Timeout)
The Min ACK Timeout was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D59
Fieldbus Error
(DPRAM Writing and Reading)
The DPRAM writing and reading error was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D5A
Fieldbus Error
(TOGGLE Timeout)
The TOGGLE Timeout was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D5B
Fieldbus Error
(Access Right Retry Over)
The Access Right Retry Over Error was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D5D
Fieldbus Error
(FBRS Link Error)
The FBRS Link Error was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D5E
Fieldbus Error
(Mail BOX Response)
The Mail BOX Response Error was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the front of the
board.
D5F
Network I/F Module Class Mismatch
Error
The type of I/F module specified in I/O Parameter No.225 and
the type of network module actually mounted do not match.
Check the setting in I/O Parameter No.225 and the combination
of network I/F module actually mounted.
D75 Fieldbus Parameter Error
There is a failure in the Fieldbus Parameter. Check in I/O
Parameters No.226.
D77
Fieldbus Error
(Exception)
The Exception Error was detected.
Refer to the operation manual of the field network board and
check the conditions of monitoring LEDs on the Fieldbus.
E1F I/O Assignment Parameter Error
It can be concerned that a value other than the input and output
port number (-1 is acceptable) or a value other than Input and
Output Board Top No. + [a multiple of 8] is input in I/O
Parameter No.2 to�9, or a value other than [a multiple of 8] is
input in I/O Parameter No.14 to 17.
E20 I/O Duplication Assignment Error
I/O assignment is duplicated. Check I/O Parameter No.2 to 9,
14 to 17, card model code (input and output number) in the slot
and so on.
E21 I/O Assignment Number Overflow Error
I/O assignment has exceeded the specified range. Check I/O
Parameter No.2 to 9, 14 to 17, card model code (input and
output number) in the slot and so on.
E8F Fieldbus Logic Error It is a logic error at the Fieldbus initializing.
