3. XSEL-R/S/RX/SX/RXD/SXD
11
3. XSEL-R/S/RX/SX/RXD/SXD
3.1 Operation Modes and Functions
XSEL Controllers applicable for EtherCAT® are applicable for the remote I/O control (*1) (256
points max. for each input and output).
*1 I/O port is controlled in one port unit. I/O port is a point to receive and send data located
inside the controller. 1 port can handle data of 1 contact (1 bit).
Data are sent and received via either PIO (24V input and output) or field network.
Connection to one port is available from only one of PIO or field network. Set a parameter
to determine which of PIO or field network is to be used.
� Operation Image
PLC (host)
I/O Unit
EtherCAT®
Master Unit
Data Transfer
Data Transfer
I/O Port
(Input) Port (Output) Port
000 300
001 301
002 302
003 303
004 304
005 305
006 306
007 307
008 308
009 309
010 310
011 311
012 312
013 313
014 314
015 315
016 316
017 317
018 318
019 319
020 320
321
……
……
1 Port
XSEL Cntroller
I/O Interface
� Extension I/O
Board
� Multipoint I/O
Board
EtherCAT®
Interface
(EtherCAT®
Board)
Connected
internally
(Assignment
done by
parameter
settings)
shows the data flow.
