Page 53
47
6. Inspection/Maintenance
6.5.2 Starting the Absolute Reset Menu
(1)
Open the absolute reset window from the PC software.
(2)
The absolute reset window opens.
x One of three absolute reset screens—for arm 1, arm 2 and rotational axis + vertical axis—is
displayed when a corresponding tab is clicked.
Absolute reset screen
for arm 1 or 2
Absolute reset
screen for rotational
axis + vertical axis
