BR-SmartMedia in DMX-512 Recorder Mode
For a BR-SmartMedia in Intelix mode, the menu will appear as follows. At the top
of the screen the size of the AutoDownload file found on the SmartMedia Flash
Card (if any) is shown. If the AutoDownload file isn't found, then 'not found' will ap-
pear in this space. If now AutoDownload file is found, then many of the following
DMX-512 Recorder Mode commands will be unavailable:
-Gilderfluke & Company - BR-SmartMedia in BR-Serial Mode - v1.22 - [c]2003 DCM-
_11 shows with _27 channels @ __0 Offset / Set FileName is TEST____.A00
Card Address- __0
a) DMX- Tx & Rx w/CS
b) baud rate- forced to 9600 baud
c) numbering system- decimal
d) VT-52 display- yes
e) EaseIn speed- 2.1 seconds
h) operating mode- Serial RealTime Updates
v) monitor channel- none
u) 1st channel offset- __0
l) string trigger channel- none
m) edit strings....
g) analogs to EaseIn | h) operating mode | i) Info | o) reload config.
p) Play a show | r) save config. | t) Test shows | x) eXit
Enter Command-
a) DMX-512: Please refer to the MultiShow section of this manual.
b) Numbering System: Please refer to the MultiShow section of this
manual.
c) VT-52 Compatible Display: Please refer to the MultiShow section
of this manual.
e) Ease-In Speed: Please refer to the MultiShow section of this man-
ual.
f) Current Show: This is a DMX-512 Recorder Mode specific com-
mand. It is used to pick which show in the current AutoDownload
file on the BR-SmartMedia will be recorded over or erased.
r) Record Show: This is a DMX-512 Recorder Mode specific com-
mand. This begins the process of sampling DMX-512 data into the
show specified by the command above. If the BR-SmartMedia is
