i) Information: This will display a status report for the BR-SmartMedia.
The status for each of the eight sequencers are displayed, as are
the current states of the ten optoisolated inputs.
-Gilderfluke & Company - BR-SmartMedia in Multi-Show Mode - v1.17 - [c]2002 DCM-
__9 shows with 232 channels @ __0 Offset / Set FileName is CROOM1__.A00
Card Address- __0
Sequencer a show #__1 CRoom1_A looping @ frame 000421h / 1057
Sequencer b show #__2 CRoom1_B looping @ frame 0003C2h / 962
Sequencer c show #__3 CRoom1_C looping @ frame 0002F7h / 759
Sequencer d show #__4 CRoom1_D looping @ frame 00029Fh / 671
Sequencer e show #__5 CRoom1_E looping @ frame 00024Dh / 589
Sequencer f show #__6 CRoom1_F looping @ frame 00020Bh / 523
Sequencer g show #__7 CRoom1_G looping @ frame 0001CCh / 460
Sequencer h show #__8 CRoom1_H looping @ frame 000172h / 370
input 0: open
input 1: open
input 2: open
input 3: open
input 4: open
input 5: open
input 6: open
input 7: open
Blue input: open
Green input: open
i) to redraw, n) any other key to return to main menu -
(Sample data: Your show data will differ from what is shown.)
This is a snapshot view of the status of the card. To get anoth-
er snapshot, just hit the command again.
o) Reload Configuration: This command gives you the option of:
1) Reloading the default configuration into the BR-
SmartMedia’s configuration EEprom.
2) Loading a previously saved configuration file to the BR-
SmartMedia’s configuration EEprom. (This option is only
available if there is a SmartMedia Flash Card installed on
the BR-SmartMedia)
