v) Monitor Channel: Please refer to the MIDI section of this manual.
j)
Intelix Strings: This is a Intelix Mode specific command. This com-
mand is used to set up the commands that the Intelix Matrix mixer
will respond to. The format of all Intelix strings is pretty similar. The
typical string to use with the BR-SmartMedia is the one that adjusts
the level of a single matrix mixer cross point in real time.
-Gilderfluke & Company - BR-SmartMedia in BR-Serial Mode - v1.22 - [c]2003 DCM-
__9 shows with 232 channels @ __0 Offset / Set FileName is CROOM1__.A00
Card Address- __0
Channel 1 2 3 4 5 6 7 8 9
0) _20 |251|__0|__5|__2|_14|__4|__5|__0|__0|
1) xxx |___|___|___|___|___|___|___|___|___|
2) xxx |___|___|___|___|___|___|___|___|___|
3) xxx |___|___|___|___|___|___|___|___|___|
4) xxx |___|___|___|___|___|___|___|___|___|
5) xxx |___|___|___|___|___|___|___|___|___|
6) xxx |___|___|___|___|___|___|___|___|___|
7) xxx |___|___|___|___|___|___|___|___|___|
8) xxx |___|___|___|___|___|___|___|___|___|
9) xxx |___|___|___|___|___|___|___|___|___|
A) xxx |___|___|___|___|___|___|___|___|___|
B) xxx |___|___|___|___|___|___|___|___|___|
C) xxx |___|___|___|___|___|___|___|___|___|
D) xxx |___|___|___|___|___|___|___|___|___|
E) xxx |___|___|___|___|___|___|___|___|___|
F) xxx |___|___|___|___|___|___|___|___|___|
enter number of string to edit, or ape to return to main menu (0-F)-
(Sample data: Your show data will differ from what is shown.)
In this example, the audio which is present on input number
four is being sent to output number five. The level of the mix is set
by animation channel twenty.
‘251’ (header for all commands), ‘0’ (MSB of command
length), ‘5’ (LSB of command length), ‘2’ (class), ‘14 (message
I.D.)’, 4 (input number), 5 (output number)
Consult the Intelix programming manual for specifics on all
other Intelix serial commands.
The Intelix mixer currently supports baud rates of 9600, 19.2
KBaud and 38.4 KBaud. There is no reason to use anything but
the highest rate available. The maximum string length for the ma-
trix mix commands is eleven bytes. The maximum number of ma-
