BR-SmartMedia in MIDI Mode
For a BR-SmartMedia in MIDI mode, the menu will appear as follows. At
the top of the screen the size of the AutoDownload file found on the
SmartMedia Flash Card (if any) is shown. If the AutoDownload file isn't
found, then 'not found' will appear in this space
-Gilderfluke & Company - BR-SmartMedia in BR-Serial Mode - v1.22 - [c]2003 DCM-
__9 shows with 232 channels @ __0 Offset / Set FileName is CROOM1__.A00
Card Address- __0
a) DMX- Tx & Rx w/CS
b) baud rate- forced to MIDI baud
c) numbering system- decimal
d) VT-52 display- no
e) EaseIn speed- 2.1 seconds
h) operating mode- MIDI
v) monitor channel- _10
u) MIDI keyboard channels- _11 thru _26
k) voice- 01, press vel- _64, release vel- _64
l) string trigger channel- none
m) edit strings....
g) analogs to EaseIn | h) operating mode | i) Info | o) reload config.
p) Play a show | r) save config. | t) Test shows | x) eXit
Enter Command-
a) DMX-512: Please refer to the MultiShow section of this manual.
b) Baud Rate: While using the BR-SmartMedia in MIDI mode, the sec-
ondary serial port is forced to the MIDI baud rate of 31,250 bits
per second. Please refer to the MultiShow section of the manual
for additional information on this command.
c) Numbering System: Please refer to the MultiShow section of this
manual.
d) VT-52 Compatible Display: Please refer to the MultiShow section
of this manual.
e) Ease-In Speed: Please refer to the MultiShow section of this man-
ual.
h) Operating Mode: Please refer to the MultiShow section of this
manual.
