Ribbon cable #11 21 brown secondary RS-422 ground
Ribbon cable #12 22 red secondary RS-422 Serial Rx - data into card
Ribbon cable #13 23 orange secondary RS-422 Serial Rx + data into card
Ribbon cable #14 24 yellow secondary RS-422 Serial Tx - data out of card
Ribbon cable #15 25 green secondary RS-422 Serial Tx + data out of card
Ribbon cable #16 26 blue secondary RS-422 ground
Ribbon cable #17 27 violet Green Input negative
Ribbon cable #18 28 gray Green Input positive
Ribbon cable #19 29 white Blue Input negative
Ribbon cable #20 30 black Blue Input positive
Ribbon cable #21 31 brown MIDI n/c (MIDI DIN pin #3)
Ribbon cable #22 32 red MIDI Tx - (MIDI DIN pin #5)
Ribbon cable #23 33 orange MIDI ground (MIDI DIN pin #2)
Ribbon cable #24 34 yellow MIDI Tx + (MIDI DIN pin #4)
Ribbon cable #25 35 green secondary RS-422 TxD - out from card (ver. 1.1+)
Ribbon cable #26 36 blue ground
Ribbon cable #27 37 violet secondary RS-422 TxD + out from card (ver. 1.1+)
Ribbon cable #28 38 gray ground
Ribbon cable #29 39 white secondary RS-422 Serial Rx - in to card (ver. 1.1+)
Ribbon cable #30 40 black ground
Ribbon cable #31 41 brown secondary RS-422 Serial Rx + in to card (ver. 1.1+)
Ribbon cable #32 42 red ground
Ribbon cable #33 43 orange
Ribbon cable #34 44 yellow
Ribbon cable #35 45 green
Ribbon cable #36 46 blue
Ribbon cable #37 47 violet
Ribbon cable #38 48 gray
Ribbon cable #39 49 white
Ribbon cable #40 50 black
n/a 51 black power supply ground
n/a 52 black power supply ground
n/a 53 black power supply ground
n/a 54 black power supply ground
n/a 55 black power supply ground
n/a 56 red + power supply input
n/a 57 red + power supply input
n/a 58 red + power supply input
n/a 59 red + power supply input
n/a 60 red + power supply input
