If you choose option ‘b’, the following screen will appear:
-Gilderfluke & Company - BR-SmartMedia in Multi-Show Mode - v1.22 - [c]2003 DCM-
__9 shows with 232 channels @ __0 Offset / Set FileName is CROOM1__.A00
Card Address- __0
This will create a backup of the EEPROM on the SmartMedia card.
The backup file is saved as: CONFIG.SM
Don't remove the SmartMedia card or power this unit down while the
card access LED is lit.
Hit any key when ready.
hit ape key to cancel-
Whether the backup file was saved through a serial download
or written directly to the SmartMedia Flash Card, it can be re-
stored using the ‘Restore Configuration’ command.
t) Test: This command checks the veracity of the AutoDownload file
on the SmartMedia from stem to stern. It then reports if the file
was good or corrupted.
x) eXit: This exits the configuration mode and returns the BR-
SmartMedia to the command mode. When exiting you must enter
a ‘y’ or ‘n’, to preserve compatibility with some other Gilderfluke &
Company cards.
s) Upload configuration: This command (which doesn't appear on
the menu) is the complement of the Download Configuration
command. To invoke it, all you need to do is tell your modem pro-
gram to send the file saved by the 'download' command back to
the BR-SmartMedia. This will automatically invoke the upload com-
mand and store the incoming data.
+) Data Dump: This command (which doesn't appear on the menu)
dumps out the DMX-512 output buffer and the configuration
