Operation 8 Position DIP Directive
SW1 SW2 Seconds
Factory
Default
Setting California
setting
Chicago
settings
OFF OFF zero √
ON OFF 1 √ fixed √ fixed
OFF ON 2
~ NDA ~
Nuisance Delay
Alarm
Matrix
ON ON 3
SW3
Cycle
Time
OFF 15 √ √ fixed √ fixed
~ IRA ~
Irrevocable Alarm
ON 30
SW4 SW5 Seconds
OFF OFF zero √ √ √ fixed
ON OFF 5
OFF ON 10
~ BDT ~
Bypass Delay Time
(External Only)
Matrix
ON ON 15
SW6 Function
OFF Disabled √ √ √ fixed
~ PAR ~
Post Alarm
Reminder ON Enabled
SW7 Function
OFF Disabled √ √ √ fixed
~ BEA ~
Bypass Expiration
Alarm
ON Enabled
SW8 Function
OFF Manual √ √ fixed
~ MDR ~
Manual/Delayed
Relock
ON Delayed √ fixed
Table A
DIP Switch Settings Matrix
NDA (Nuisance Delay Alarm) – DIP SW1 and SW2
NDA is a zero, 1, 2 or 3 second nuisance or warning delay (revocable) which initiates when door
movement is detected. When triggered the local alarm will sound (pulsing tone). The factory
default setting is zero seconds and is changed via DIP switch settings of SW1 and SW2. (This
setting is fixed to 1 second on the Chicago and California versions)
IRA (Irrevocable Alarm) – DIP SW3
IRA is an irrevocable alarm which initiates when door movement is detected. Once initiated the
complete delay cycle must expire prior to reset. This is a set 15 or 30 second total alarm time
cycle including any NDA time. The audible alarm sounds until the IRA expires. The factory
default setting is 15 seconds but can be changed to 30 seconds by changing DIP switch SW3.
(This setting is fixed to 15 seconds on the Chicago and California versions)
BDT (Bypass Delay Time) – DIP SW4 and SW5
BDT is an external switch bypass function only. Once triggered, a set zero, 5, 10 or 15 second
release time is initiated. The factory default setting is zero but it can be set to 5, 10 or 15
second (trailing edge trigger) by changing DIP switches SW4 and SW5. (This setting is fixed to
zero on the Chicago version)
PAR (Post Alarm Reminder) – DIP SW6
PAR is an audible alarm indicating the lock has completed an alarm cycle. After 5 seconds the
internal alarm will beep rapidly 3 times followed by 5 seconds of silence and will repeat until
reset. The factory default setting is off but PAR can be turned on with DIP switch SW6. Note:
This feature will not operate if a voltage is maintained on the “RS” terminal (See
Figure 13). (This setting is disabled on the Chicago version)
