Magnalock, Preparation 1 – Securitron M380BD User Manual
Page 3
PN# 500-23300
Page 3
Rev. B, 07/13
Magnalock
Preparation
1.
Using a Phillips screwdriver, remove the two (2) screws securing the cover as shown.
Remove the cover to provide access to the circuit board on the back of the magnet.
The screws should be saved to re-attach the cover later.
2.
Component Locations
M370:
M380BD:
Quick Clip 1:
Configuration
SW3
J1
J1
JP3
JP4
SW3
