Figure 2 – Reese 56002 OUTBOARD CUSTOM QUICK INSTALL KIT User Manual
Page 7
27 5/8"
DIMENSIONS SPÉCIFIQUES POUR ENSEMBLE
DE TRAVERSES DE MONTAGE 30153
.
.
EMPLACEMENTS DES
TROUS ET BOULONS
.
7/8"
Figure 2
©
2011 Cequent Performance Products, Inc.
Feuille 7 de 12
56002N
9/8/11
Rev. A
SUPPORT DE CADRE
CADRE
SUPPORT D'ATTELAGE/CURSEUR/
COL-DE-CYGNE
(SUPPORT D'ATTELAGE ILLUSTRÉ)
TRAVERSE DE
MONTAGE
LIGNE DE CENTRE DE L'ATTELAGE
LIGNE DE CENTRE DE
L'ATTELAGE
APPROX.
AVANT DU
VÉHICULE
