Figura 2 – Reese 56002 OUTBOARD CUSTOM QUICK INSTALL KIT User Manual
Page 11
27 5/8"
DIMENSIONES ESPECÍFICAS PARA
EL KIT DE LARGUEROS 30153
.
.
UBICACIONES DE
PERFORACIÓN Y PERNOS
.
7/8"
Figura 2
©
2011 Cequent Performance Products, Inc.
Hoja 11 de 12
56002N
9/8/11
Rev. A
SOPORTE DEL BASTIDOR
BASTIDOR
SOPORTE DEL ENGANCHE /
DESLIZADOR / GANSO (SOPORTE
DEL ENGANCHE SE MUESTRA)
LARGUERO DE
MONTAJE
LÍNEA CENTRAL DEL ENGANCHE
LÍNEA CENTRAL DEL
ENGANCHE
APROX.
FRENTE DEL
VEHÍCULO
