PC-Gentec- EO User’s Manual Revision 5.0 8
Default Trigger Level 2 %
SOFTWARE
TRIGGER LEVEL
0.1% to 99.9%, 0.1% resolution
Transfer Rate for
MAESTRO No missing points throughput serial frequency (power and energy):
500 Hz
For higher repetition rate, please use directly the MAESTRO
Refer to MAESTRO specification
4
:
Transfer Rate for
Integra No missing points throughput serial frequency (power and energy):
5200 Hz
Frequency
Measurement MAESTRO: Accurate frequency measurement up to 14kHz
0-1000 Hz: 0.1% accuracy
1000-2000 Hz: 0.5%
2000-14000 Hz: 1%
INTEGRA: Accurate frequency measurement up to 5.2kHz
0-5200 Hz: 1%
Statistics Current value, Max, Min, Average, Std Dev., RMS stability, PTP stability,
Time, Pulse #.
General Specifications
Serial
Communication Maestro and Integra USB
MAESTRO: RS-232
NOT AVAILABLE : Ethernet
Data Displays Real Time, Scope, Averaging, Statistics, Digital Tuning Needle,
Histogram
User input correction
factors
1 multiplier and 1 offset (7 digits floating point)
Internet Upgrades Downloadable link
Size 4.39 MB
Average RAM
allocation
9 to 23 MB
PC Recommended
Requirement Dual Core Processor
3 Gb of RAM
Operating System
Compatibility Windows 7
Windows Vista
Windows XP (not officially supported)
4 In a full size statistic’s windows, no scope display and no serial communication.
