PC-Gentec- EO User’s Manual Revision 5.0 47
GAS None 1: On
0: Off
Example Response from Monitor
Command: *GAS AutoScale : 1 \r\n
Display Valid Range
This command is used to display all of the valid ranges the connected head supports. The
ranges are displayed in scale index. Please refer to the Set Range section for the table
correspondence.
Command Parameters Return
DVS None The valid scale index.
The following example is for a UP19K connected to the MAESTRO, which can have the following
ranges:

100 mW;

300 mW;

1 W;

3 W;

10 W;

30 W.
Example Response from Monitor
Command: *DVS [22] : 100.0 m
[23] : 300 m
[24] : 1.000
[25] : 3.00
[26] : 10.00
[27] : 30.0
Set Trigger Level
This command sets the internal trigger level when using the device in energy reading mode.
Text Command Parameters Return
STL Trigger Level (in percentage) must
be 4 numeral values
Default: 2%
