Gentec-EO PC-Gentec-EO (for MAESTRO and INTEGRA) - Manual (Page 47)

PC-Gentec- EO User’s Manual Revision 5.0 46
Command: *SCS08
Get Current Range Index
This command returns the range index between 0 and 41. Please refer to Set Range command
(SCS) details for the complete range index table.
Text Command Parameters Return
GCR None Index from 0 to 41
Example Response from Monitor
Command: *GCR Range : 10 \r\n
Set Range Up
This command is used to force the display of the current data into a higher range
Command Parameters Return
SSU None
Set Range Down
This command is used to force the display of the current data into a lower range.
Command Parameters Return
SSD None
Set Autoscale
This command is used to force the display into autoscale.
Command Parameters Return
SAS 0 = off
1 = on
Get Autoscale
This command returns whether or not the autoscale option is activated.
Text Command Parameters Return
