It is possible to have live on-screen statistics with this graphical mode. Simply go in the

“Set Display”

panel using the Settings

button and click

“Display Stats”. To restart the graph, use the Refresh

button directly in the graphic panel.

Fig. 5-6 Scope display with Statistics

5.2.1.1

Scope Display - Options Panel

The options panel for the scope display allows to control the number of digits, to change the period of the
graphic, to change the minimum/maximum value of the scope when selecting a range and to show/hide
the on-screen statistics.

Fig. 5-7 Scope display options panel
