PC-Gentec- EO User’s Manual Revision 5.0 58
:0 0028 E1 20 á
:0 0029 00 3A :
:0 002A 39 31 1 9 Detector serial number (You must convert the
:0 002B 36 39 9 6 hexadecimal values in ASCII characters)
:0 002C 32 37 7 2
:0 002D 00 00 0000 = Null termination character
:1 0000 00 00 End of structure
Query Extended Status
This command is used to query the device to get information about the following characteristics:

Measure Mode

Maximum, minimum and current scale;

Maximum, minimum and current wavelength with and without attenuation;

Attenuator availability and status;
 Detector’s head model;
 Detector’s serial number.

Trigger level (0.001 to 0.999)

Autoscale mode

Anticipation mode

Zero offset mode

User correction multiplier

User correction offset
Text Command Parameters Return
ST2 None A hexadecimal structure
described in the table below.
The first byte represents the validity of the structure: 0 represents a valid line while 1 is the end of the
structure. The next 4 bytes represent the address line and the last 4 bytes are the actual value. The
values are written on 32 bits, which means that all the values are written on two lines. The first line
represents the LSB and the second line represents the MSB.
The following table shows the output when a XLP12-3S-H2-D0 serial number 199672 is connected to the
MAESTRO.
Hexadecimal structure Converted
Definition
Valid Address Value Value
:0 0000 3 3 Reserved
:0 0001 0 0 Reserved
