PC-Gentec- EO User’s Manual Revision 5.0 53
The following example sets multiplier = 33
Example Response from Monitor
Text Command: *MUL3300000
Or
*MUL3.3000e3
Get User Multiplier
This command returns the MAESTRO’s correction multiplier value.
Text Command Parameters Return
GUM None Current multiplier value
Example Response from Monitor
Command: *GUM User Multiplier : 1 \r\n
Set User Offset
This command is used to set the value of the offset.
Text Command Parameters Return
OFF 8 characters numeral value
Default: 0
The following example sets offset to 1.5 milli.
Example Response from Monitor
Text Command: *OFF0.001500
OR
*OFF1.500e-3
The other option available is the Zero-offset. The Zero-offset operation is done first, before those
of the Multipliers and Offsets
Get User Offset
This command returns the MAESTRO’s correction offset value.
Text Command Parameters Return
GUO None Current offset value
