03/10 37 50614 Rev. 5
Appendix V: Tolerances:
Load Cell Grout Plates, level within 0.015" per Foot
Appendix VI: Loadcell Specifications:
Type: LCF-HR4020-4A
COC #97078 / Class III L, Single: 10,000 d
Safe Load Limit: 150% of Rated Capacity.
Capacity: 110,000 LB.
Height: 7 "
Input Resistance: 1150 ohms
Output Resistance: 1000 ohms
Insulation Resistance: 10 giga ohms (1000 meg ohms)
Calibration: 2 mV/V
Cable Length: 15 feet
Minimum Verification Intervals (V MIN): 50K lb: 1.5 lb
100K lb: 3.0 lb
200K lb: 6.0 lb
Wiring: Excitation (+) = Green
Excitation (-) = Black
Output (+) = White
Output (-) = Red
Appendix VII: Ground Rod Kit Packing List:
Assy # Description
60811 Copper Plated Ground Rod: 3/4" X 8 '
65061 Ground Rod Clamp
79385 Ground Braid Clamp
11296 Braid, Ground Shield, 5/8 ID #8
58618 Ground Rod Cap
79386 Hex Cap Screw 5/16-18 X 1 1/2"
54224 5/16-18 Hex nut
54760 5/16" Spring Lock Washer
