Fairbanks 2000 SERIES Rocker Column Railroad Scale User Manual
Page 34
03/10
34
50614 Rev. 5
Parts Not Pictured:
Part# Description
Qty
59600
Cut ¼" Steel Plates (2" X 2" Square)
59795
5/8-11 X 4" Chk Stand Leveling Screw
54591
¾-10 X 6" Base Plate Leveling Screw
Weighbridge Assembly Bolts
54532
¾-10 X 3" Hex Bolt
54229
¾-10 X 3 ½" Hex Bolt A325 with Nut
54199
¾ -10 X 2 ¼" Hex Bolt with Nut.
54217
¾-10 X 3" Hex Bolt A325 with Nut
54402
1" X 3 ½" Hex Bolt A325 with Nut
Misc Hardware
54342
1 ½-6 Hex Nut (Check Rods)
54897
1 ½-6 Jam Nut (Check Rods)
58617
1 ½ Spherical Washer Set (Check Rods)
61260
1/8" X 12" X 3' Junction Box Plate
55766
¾" X 1 ¼" X 5" Bar, J Box
Grounding Kit Components
60811
¾" X 8' Ground Rod, Copper Plated,
65061
Clamp, Ground Rod
79385
Set Screw, Ground Braid Clamp
11296
5/8" ID, #8 AWG Braided Ground Strap,
58618
Ground Rod Cap, PVC
79386
5/16-18 X 1 ½" Hex Cap Screw
54224
5/16-18 Hex Nut
54760
5/16" Spring Lock Washer
