Fairbanks 2000 SERIES Rocker Column Railroad Scale - Manual (Page 33)

03/10 33 50614 Rev. 5
Item
No.
Part No. Description
1 72681 Weighbridge Assembly (single)
2 73784 Weighbridge Assembly (double)
3 74001 Grout Plate 1 1/2" x 20" x 21" ( interior)
4 72661 Grout Plate 1 1/2" x 20" x 21" ( ends)
5 72689 Approach Column
6 54664 Bolt, Hex 1"-8 x 2 1/2"
7 54782 Washer, Lock 1"
8 72139 Load Cell 100K, LCF-HR4020-4A, NTEP CoC #97078
9 72662 Receiver Plate, Lower w/ bearing 1" thk, Hardened RC50-55
10 73972 Clamp Plate
11 54532 Bolt, Hex 3/4" - 10 x 3"
12 54776 Washer, Lock 3/4"
13 72663 Receiver Plate, Upper
14 54555 Bolt, Hex 3/4" -10 x3 1/2"
15 54233 Washer, Flat 3/4"
16 54776 Washer, Lock 3/4"
17 54264 Nut, Hex 3/4"
18 70508 Bearing, Upper 1" thk, Hardened RC 50-55
19 73785 Connector Plate, Web 1" x 4 3/4" x 9 1/2"
20 54391 Bolt, Hex 3/4" - 10" x 6" A325 w/nut
21 72674 Check Bracket, RH
22 72673 Check Bracket, LH
23 74023 Bolt, Hex 1 1/8" x 4"
24 54255 Washer, Flat 1 1/8"
25 54788 Washer, Lock 1 1/8"
26 54304 Bolt, Hex 1 1/8"
27 74003 Clamp Plate 3/4"
28 74009 Bumper Shim Plate, 1/16"
29 74007 Bumper Shim Plate, 1/8"
30 74005 Bumper Shim Plate, 1/4"
31 74024 Bolt, Hex 3/4" - 16 x 3"
32 54776 Washer, Lock 3/4"
33 72668 Anti-Creep Weldment for Weighbridge
34 84353 Anti-Creep Spacer, 1”
35 54435 Bolt, Hex 1" x 4 1/4" w/Nut
36 62145 Anti-Creep Weldment for Approach
