Fairbanks 2000 SERIES Rocker Column Railroad Scale - Manual (Page 19)

03/10 19 50614 Rev. 5
2-H: Foundation Inspection Check list
Length & Width Check
Diagonal Measurements
Check
A B
Pier Height Check
Pier Pier
Side View
Strings
1
2
3
4
5
6
7
8
9
10
1:
2:
3:
4:
Measurement A to A=________
Measurement B to B=________ B A
B
A
B
A
A = Coping length
B = 1/2 of the coping length, or Centerline
C = Distance from Centerline to load cell Center lines
CL
Loadcell Center Line
Loadcell Center Line
C
C
C
C
CL
= Concrete Nails
= Centerline of Scale
50614_15
