Appendix III: Materials:

Grout shall be precision, packaged dry, non-metallic, hydraulic, non-shrink, and non-gaseous.
Grout shall meet or exceed ASTM C-1107 and Corps of Engineers CRD-C621.
Grout shall be bleed free and attain a minimum of 8000 psi compressive strength in 28 days
at flowable consistency.
Grout MUST be mixed to a flowable consistency as specified by the grout manufacturer. "

Quantity required will vary according to pier heights. Projected amount is 3 bags per load-

cell base plate, and 2 bags per checking stand at 40lb per bag.

NOTE: Pier heights other that those indicated on the certified prints will affect the quantity
required.

Wood for forming base plates and checking stands. Select unfinished pine, 1 1/2" to 2” wide
X 12 feet long. Project quantity is one stick per base plate, and one stick per check stand.

Drywall screws suitable for constructing and securing wood forms.

Wood blocking and cribbing material, suitable for supporting the weighbridge. Sufficient quan-
tity to provide a safe, stable support from the pit floor to the bottom of the main I-beams.
Shipping weights for these scales range from 36,500 lbs to 50,000 lbs.

Materials and equipment for mixing the grout and water to a suitable consistency, and deliver-
ing it to each grout plate.

Grease: NLGI #2, Water resistant, Anti-wear Grease such as CRC Super White.

Appendix IV: Torque Values Chart

All Values are Pounds (LB).

SIZE

GRADE 2

GRADE 5

GRADE 8

LUBED

DRY

LUBED

DRY

LUBED

DRY

1/4-20

49 in

65 in

75 in

100 in

107 in

143 in

5/16-18

101 in

134 in

157 in

210 in

220 in

305 in

3/8-16

15 FT

20 FT

23 FT

31 FT

32.5 FT

44 FT

7/16-14

24 FT

30 FT

37 FT

50 FT

53 FT

70 FT

1/2-13

36.5 FT

49 FT

57 FT

75 FT

80 FT

107 FT

9/16-12

53 FT

70 FT

82 FT

109 FT

115 FT

154 FT

5/8-11

73 FT

97 FT

113 FT

151 FT

159 FT

211 FT

3/4-10

129 FT

173 FT

200 FT

266 FT

282 FT

376 FT

7/8-9

125 FT

166 FT

321 FT

430 FT

454 FT

606 FT

1-8

187.5 FT

250 FT

482.5 FT

640 FT

680 FT

900 FT
