CLASS 5000 METER
62-0392-03 48
12.0 PROTOCOL DESCRIPTIONS
ModBus Customer Point Map: CL5000
Address Registers Format Description Units
CL
5000
40001
1 2 Integer Energy delivered Wh Pulse R/W
40003
1 2 Integer Energy received Wh Pulse R/W
40005
1 2 Integer Reactive energy delivered VARh Pulse R/W
40007
1 2 Integer Reactive energy received VARh Pulse R/W
41001
1 2 Float Energy delivered kWh R/W
41003
1 2 Float Energy received kWh R/W
41005
1 2 Float Reactive energy delivered kVARh R/W
41007
1 2 Float Reactive energy received kVARh R/W
41009 2 Float Real power kW R
41011 2 Float Reactive power kVAR R
41013 2 Float Apparent power kVA R
41015 2 Float Power factor % PF R
41017 2 Float Peak demand kW R
41019 2 Float Current average Amps R
41021 2 Float Voltage line-neutral Volts-N R
41023 2 Float Voltage line-line Volts-L R
41025 2 Float Frequency Hz R
41027 2 Float Phase angle Degree R
41029 2 Float Real power, phase A kW R
41031 2 Float Real power, phase B kW R
41033 2 Float Real power, phase C kW R
