Maintenance Model 6700C TOC
Teledyne Analytical Instruments 48
3. Disconnect connectors.
4. Slide Power Supply off the Din Rail.
5. Remove Power Supply Module.
6. Replace Power Supply Module.
7. Reverse steps for installation.
8. Recalibrate liquid and span values.
Figure 5-3: DC Power Supply
5.3.5 Computer
If malfunctioning, exchange Computer Module using the
directions below. See Figure 5-4.
Procedure:
1. Turn off power
2. Disconnect electrical connectors.
3. Remove screws holding Module in place.
4. Remove module.
5. 5. Install new CE Computer in reverse disassembly instruction
procedure steps. Recalibrate liquid zero and span values.
