High Temperature Combustion Operation
Teledyne Analytical Instruments 35
The following screen appears:
Disconnect the tubing from the GLS and connect the “IR”
calibration adapter (P/N A1000) to the calibration gas cylinder tubing as
shown in Figure 4-1. TAI recommends using the Cal. Gas Kit P/N
K258 (1.0% CO
2
) or K259 (0.1% CO
2
).
Figure 4-1: Connecting Calibration Adapter
