Part 2 Analysis Unit Model 3010MA
86 Teledyne Analytical Instruments
2. Zero (with N
2
gas) the analyzer with no restriction on vent (needle
valve fully open)
3. Span (with O
2
gas) the analyzer with no restriction on vent (needle
valve fully open)
4. Change pressure compensation factor to 0.00
 Press the System key
 select the ‘PressureAdj’ function
 Then press Enter
 Verify that the compensation factor is set to 0.00, adjust if
required
 Press the Escape key
5. Record the oxygen reading with the span gas flowing, (100% O2)
and needle valve on the vent fully open.
 Press the System key
 Select the ‘More’ function
 On the second System screen, record the A to D pressure counts.
The A to D pressure counts are shown on the second line of the
VFD. The example below would be typical for a 3010M analyzer
with Valve Box compatible software. The first number in the
second line is the paramagnetic sensor voltage output (0.993VDC)
and the second number is the A to D pressure counts (112210).
Ver Test Ser# Stream
0.993 112210 More
6. Record the oxygen reading with the span gas flowing, (100% O2)
and needle valve on the vent slightly closed.
 While still on the second System screen, slowly begin to close the
needle valve. Observe the A to D pressure counts as they rise, stop
once the counts are approximately 1000 counts over the value you
recorded in step 5 (the increase does not have to be exactly 1000
counts).
 Wait for stability, about three to five minutes.
 Return to the Analyze screen by pressing the Analyze key, record
the oxygen reading.
7. Compute the pressure compensation factor. See Example 1 shown
below.
