Paramagnetic O2 Purity Analyzer

Introduction

Teledyne Analytical Instruments

15

Introduction

1.1 Overview

The Teledyne Analytical Instruments Model 3010MA Paramagnetic

Oxygen Purity Analyzer is a versatile microprocessor-based instrument
for detecting the percentage of oxygen in a gas stream. This part of the
manual covers the Model 3010MA flush-panel and/or rack-mount Control
Unit. These units are for indoor use in a nonhazardous environment.

In addition to supplying the interface for operating and controlling

the analyzer, the Control Unit also houses:

 Main circuit board
 PID temperature controller
 Pressure compensation circuitry
 24VDC power supply for driving the Analysis Unit
 Digital meter readout and display circuit board
 Interface screen and circuit board

1.2 Front Panel (Operator Interface)

The standard 3010MA is housed in a rugged metal case with all

controls and displays accessible from the front panel. See Figure 1-1. The
front panel has thirteen buttons for operating the analyzer, a digital meter,
and an alphanumeric display.

Function Keys:

Six touch-sensitive membrane switches are used to change the

specific function performed by the analyzer:

Analyze—Perform analysis for oxygen content of a sample gas.

System—Perform system-related tasks (described in detail in
chapter 4, Operation.).

Span—Span calibrate the analyzer.

Zero—Zero calibrate the analyzer.
