Diamond Products CC2500 (Hydraulic) - Manual (Page 51)

ITEM PART NO. QTY. DESCRIPTION
1 2501256 1 Alternator
2 2500982 1 V-Belt, 4L-260
3 6047971 1 Alternator Mount Bar
4 6047972 1 Adjustment Arm
5 6048195 1 Accessory Drive Pulley
6 2900223 2 Cap Screw, Hex Hd., M10-1.5 x 30mm
7 2900304 3 Lock Nut, M10-1.5 Nylon Insert
8 2900811 1 Cap Screw, Hex Hd., 1/2-13 x 2-1/2"
9 2900058 1 Flat Washer, 1/2" SAE
10 2900026 1 Lock Nut, 1/2-13 Nylon
11 2900019 1 Cap Screw, Hex Hd., 5/16-18 x 3/4"
12 2900031 1 Lock Washer, 5/16" Split
13 2900022 4 Flat Washer, 5/16" SAE
14 2900036 2 Set Screw, Soc. Hd., 5/16-18 x 1/4"
15 6047984 1 Frame Lift
16 6047953 1 Frame Lift Brace
17 2900315 1 Cap Screw, Hex Hd., M10-1.5 x 35mm
18 2900113 1 Lock Washer, 5/8" Split
19 2900685 1 Jam Nut, 5/8-18
Alternator Assembly Option for Hydraulic Saws (Power Raise)
#6047895
51
