Diamond Products CC2500 (Hydraulic) User Manual
Page 13
Screw Feed Assembly
#6047702
ITEM PART
NO.
QTY.
DESCRIPTION
1
6047929
1
Adjustment Screw
2
6047927
1
Adjustment Shaft
3
2900354
1
Clevis Pin, 1/2" x 1-3/4"
4
2900276
1
Hairpin Cotter, 1/8" x 1/2" to 3/4"
5
2900062
1
Grease Fitting, 1/8" NPT
6
2500807
1
Bearing, 5/8", Two Bolt Flange
7
6047931
1
Spacer Tube 7/8 x 1/2
8
2900311
2
Cap Screw, Hex Hd., M6 x 25mm
9
2900009
4
Flat Washer, 1/4" SAE
10
2900302
2
Lock Nut, M6 Nylon
11
2500800
1
Handwheel, 8" x 5/8"
12
2900355
1
Lock Nut, 5/8-18, Flex Top
13
6047216
1
Bracket, Handwheel Lock
14
2400138
1
Indexing Plunger, 1/2-13 UNC
15
2900129
1
Jam Nut, 1/2-13
16
2900309
4
Cap Screw, Hex Hd., M5 x 20mm
17
2900016
4
Flat Washer, #10 USS
18
2900301
4
Lock Nut, M5 Nylon
