Diamond Products CC2500 (Hydraulic) User Manual
Page 37
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600064
1
Hydraulic Motor, Danfoss 1.94 cu. in.
2
2900357
2
Cap Screw, Soc. Hd., 3/8-16 x 1-1/2"
3
2900006
8
Lock Washer, 3/8" Split
4
6048229
1
Key, 3/16" Sq. x 1-1/4"
5
4699901
1
Shim For Hydraulic Spindle Shaft
6
2500686
2
Bearing, 50mm x 90mm x 20mm
7
6048115
1
Pillow Block
8
2900062
1
Grease Fitting, 1/8" NPT
9
6048116
1
Hydraulic Spindle Shaft
10
6047977
1
Key, 1/4" Sq. x 3"
11
6048117
1
Seal Plate
12
2900235
4
Cap Screw, Flat Hd., 3/8-16 x 1"
13
3200004
1
Seal, 1-1/8" x 2" x 1/4"
14
6048195
1
Pulley, 1-1/8" Bore
15
2900036
2
Set Screw, Soc. Hd., 5/16-18 x 1/4"
16
2500849
1
V-Belt, 4L-500
17
2500817
1
Sheave, 3.00-3V-4 Groove
18
2500029
1
Taper Bushing, 1-1/8" with Set Screws
19
2900484
2
Set Screw, Soc. Hd., 3/8-16 x 5/8"
20
2500792
4
V-Belt, 3VX400
21
2900521
2
Tap Bolt, Hex Hd., 3/8-16 x 2-1/2"
22
2900005
4
Cap Screw, Hex Hd., 3/8-16 x 1"
23
2900014
6
Flat Washer, 3/8" SAE
24
2900033
2
Hex Nut, 3/8-16
25
6048255
1
Saw Weight
26
3200005
1
Ball Valve, 3/4" Pipe
27
3200083
2
Tee, 3/4" Pipe Run
28
3200100
1
Coupler, 3/4" Quick Disconnect
29
3200101
1
Nipple, 3/4" Quick Disconnect
30
2900369
2
U-Bolt, 3/4" Pipe
31
2900125
4
Hex Nut, 1/4-20
32
2900024
4
Lock Washer, 1/4" Split
33
2900009
4
Flat Washer, 1/4" SAE
34
6048214
1
Hose, 3/4" x 34" Return
35
6048136
1
Hose, 3/4" x 28" Pressure
36
3200110
1
Elbow, 1/2" M. Pipe to 3/4" M. JIC
37
3200111
1
Elbow, 1" M. Pipe to 3/4" M. JIC
Hydraulic Motor Option for 26" Blade Guards #6049026
