Diamond Products CC2500 (Hydraulic) User Manual
Page 45
Electric Power Raise/Lower Assembly
#6047967
Rocker Switch Assembly
#6047969
Circuit Breaker Assembly
#6047979
ITEM PART
NO.
QTY.
DESCRIPTION
1
2500930
1
Actuator
2
6047965
1
Actuator Clevis
3
2900009
2
Flat Washer, 1/4" SAE
4
2900302
2
Lock Nut, M6-1.0 Nylon Insert
5
2900393
1
Clevis Pin, 1/2 x 1-3/4", Zinc Plated
6
2900276
2
Hairpin Cotter, 1/8" x 1/2" to 3/4"
7
6047966
1
Cable Connecting Arm
8
2900109
1
Jam Nut, 1/2-20
9
2500931
1
Rod End, 1/2-20 Male
10
2900354
1
Clevis Pin, 1/2" x 1-3/4"
11
6047969
1
Rocker Switch Assembly
12
6047979
1
Circuit Breaker Assembly
13
2900311
2
Cap Screw, Hex Hd., M6-1.0 x 25mm
ITEM PART
NO.
QTY.
DESCRIPTION
14
2800261
1
Rocker Panel Gasket
15
2800258
1
Rocker Switch Body
16
2800260
1
Rocker Mount Panel
17
2800259
1
Rocker Switch Actuator
ITEM PART
NO.
QTY.
DESCRIPTION
18
2800363
1
Circuit Breaker 20 Amp
19
2800364
1
Circuit Breaker Boot
20
2900309
2
Cap Screw, Hex Hd., M5-0.8 x 20mm
21
2900016
2
Flat Washer, #10 USS
22
2900301
2
Lock Nut, M5-0.8 Nylon Insert
45
