Diamond Products CC2500 (Hydraulic) User Manual
Page 39
15
1801369A
1
Blade Guard Size Tag
18
2900287
2
Rivet, 1/8" Dia.
19
1802090
2
Label, Wedge Locking Washer
20
6048026
1
Hinge Assembly
2900308
4
Cap Screw, Flat Hd., M6-1.0 x 16mm
16
1800001
1
Warning Label
17
ITEM
PART NO.
QTY.
DESCRIPTION
1
6010601
1
14" Blade Guard Front & Rear Only
2
6010081
1
Splash Flap
3
2900310
2
Cap Screw, Hex Hd., M6-1.0 x 20mm
4
2901494
4
Flat Washer, M6
5
2900083
2
Fender Washer, 1/4" x 1-1/4"
6
2900302
8
Lock Nut, M6-1.0 Nylon Insert
7
6010261
1
Water Manifold
8
2500830
1
Water Manifold Gasket
9
2901355
2
Cap Screw, Hex Hd., M6-1.0 x 50mm
10
3200001
3
Plug, 1/8" NPT
11
3200002
1
Fitting, 3/8" M. Pipe to 3/4" M. Garden
12
2900278
1
Lanyard with Lock Pin
13
6048283
2
Water Tube for 14" Guard
14
6048155
2
Water Tube Clamp
ITEM
PART NO.
QTY.
DESCRIPTION
21
2500270
1
Blade Guard Hinge
22
2900310
5
Cap Screw, Hex Hd., M6-1.0 x 20mm
23
2901494
6
Flat Washer, M6
24
2900302
7
Lock Nut, M6-1.0 Nylon Insert
25
2900312
1
Cap Screw, Hex Hd., M6-1.0 x 35mm
14" Blade Guard Assembly #6010950
