Back of pc, Back of flexmap 3d instrument – Luminex FLEXMAP 3D Hardware User Manual User Manual
Page 63
1. Place the PC and monitor on the right side of the instrument.
2. Connect the FLEXMAP 3D instrument and all necessary peripheral devices to the PC.
FIGURE 24.
Back of PC
1
Monitor Plug
4
Barcode Scanner Plug
2
FLEXMAP 3D Communications Plug (USB
type A )
5
Monitor Plug (Touchscreen monitors only)
3
Mouse Plug
6
Power Inlet
FIGURE 25.
Back of FlexMAP 3D Instrument
FLEXMAP 3D
®
Hardware User Manual
52
