Advantage Gelcoater
After draining the filter, close the filter valve.
Figure 32: Drain the Filter
Clean Gun Head
Push the flush button on the left side of the gun to flush the gun into an
appropriate container.
Remove nozzle and nozzle retainer from nozzle extension body.
Remove the nozzle extension body from gun head.
Using the turbulent mixer puller, remove the turbulent mixer from mix
chamber.
Insert the 1/4” steel rod (provided in the Gelcoater Unit Tool Kit) into the
front of nozzle extension body and press out the static mixer.
Rinse the nozzle assembly parts and the static mixer in a container of
solvent.
NOTE
Moisture should be drained from the unit daily to
prevent moisture buildup.
NOTE
Cleaning the gun head is required if you are stopping
production or there will be long pauses in operations
for lunch, part cure, or any reason.
35
Please see new
Resin Pump (p/n
85710-1) and Resin
Filter (p/n 85753-3) in
Drawing Section.
