Advantage Gelcoater
Lean the top of the catalyst pump toward the resin pump to allow trapped
air to escape (see Figure 20).
Turn the recirculation valve to the recirculation mode, towards fitting and
tube that go to catalyst jug.
Hand-Prime Catalyst Pump.
SLOWLY and GENTLY hand-prime the catalyst pump by moving the
piston rod block up and down (see Figure 21).
Gently pump material into the system until material flows steadily into
catalyst jug on both strokes (up and down) of the catalyst pump indicating
there is no more air in the pump.
Place recirculation valve into pump mode, toward blue catalyst hose.
Gently pump material into the system until material flows steadily from the
gun head on both strokes (up and down) of the catalyst pump indicating
there is no more air in the line.
Lean the catalyst pump away from the resin pump.
Trap the catalyst pump-bearing block between the quick pin and the slave
Figure 18: Lock Gun Trigger Figure 19: Pull Out Top Quick Pin
21
Please see new Resin Pump/
Slave Arm Configuration in
Drawing Section (p/n 85710-1)
