Magnum Venus Plastech ADVANTAGE User Manual
Page 14
Advantage Gelcoater
r
Figure 6: Attach Feed Line from Catalyst Jug
Figure 7: Attach Feed Line to Catalyst Pump
NOTE
Attach catalyst feed line so there are no sharp bends
or kinks in the line and the line is in a downward angle
from the jug to the catalyst pump.
NOTE
Make sure all clamps are tight to prevent leaks.
